Enclosure Material:ABS
IP Rating: IP20
Especially suitable for controlling filter fans, heaters, and heat exchangers, as well as monitoring the internal temperature of control cabinets.
| Model | TSK3110 |
| Material Code | 1018001 |
| Sensing Element | Bimetal/Electronic Type |
| Contact Configuration | Single-Pole Changeover Contact as Momentary Switch Element |
| Allowable Contact Load | K1.5-3 (Heating) AC 10(4) A, DC = 300W; K1.5-4 (Cooling) AC 5(4) A, DC = 30W |
| Temperature Adjustment Range | +5℃ to +60℃ |
| Rated Operating Voltage | 230/115/60/48/24V(AC) 60/48/24V(DC) |
| Weight | 105g |
| Dimensional | 71x71x33.5mm |
| Switching Differential | Approximately 1K ± 0.8K |
